Forks for Forklift

Forks for Forklift - There are two main styles of lift truck blades: the hook type and the pin type. Shaft mounted or likewise referred to as pin type, are typically used in bigger forklifts. This style utilizes the fork shaft or pin to be able to mount onto the lift truck. On the topmost part of the tine there is an eye that the pin could slide through. This would secure the blades to the carriage. Hook type blades are often found on forklifts as much as 14,000 lbs capacity. Hook types are name in view of the fact that they hook over and lock into the bars on the fork carriage. These types of blades could be easily mounted by means of sliding upper and lower hooks onto the end of the carriage bars. Another assembly alternative is making use of a special tine loading notch in the middle of the lower carriage mounting bar.

The industry has harmonized fork sizes and they are even load rated according to the tine thickness and width. Once a tine needs replacement, it is essential to ensure the new tine has the same load rating as the one being replaced. This fork rating shall be stamped on the shank of the fork.

Utilizing lift trucks can really reduce time and labour in many industrial applications. Having the suitable forks connected on the machine would enhance safety and efficiency.

There are various kinds of blades, so knowing the right kinds is fairly essential. Non-palletized material will need sharp ended blades to be able to slide underneath the materials and palletized materials could be safely transferred using blunt-end style forks. Ask your trainer or supervisor so as to determine the suitable blades meant for the workplace application.

Each forklift has its' own design and right manner to change the blades therefore refer to the instruction manual for your specific model. Know whether or not your unit has quick-change blades. Many newer models have this particular fork style in order to make changing forks a much easier job to carry out in less time. Consult the manufacturer's instructions to remove the forks appropriately. Most quick-change forks drop mechanically. Ensure the side shifters are situated in the proper place so the new attachment or blades fit rightly on the lift truck. Attach the lifting attachment or blades according to the lift truck's instructions. Consult the guidebook if considered necessary and when they are secured, do a safety check prior to loading the new forks for the first time.
